S215 Dew Point Sensor

Description

The SUTO S215 Dew Point Sensor provides reliable dew point monitoring in industrial applications, with long-term stability and high accuracy over the full range of -20 … +50 °C Td. Along with its compact design, this makes it the ideal solution for compressed air and gas dew point measurements in refrigeration dryers.

Dew Point Monitoring According to ISO 8573-1
The plug-and-play dew point solution monitors the compressed air quality and purity according to the ISO 8573-1 standard. Meeting these requirements helps ensure fridge-dryer efficiency and reliability.

Output Signals for Great Flexibility
The dew point transmitter is available with 2-wire or 3-wire analog 4… 20 mA output signals, as well as Modbus/RTU digital interface. By offering various output signals, the sensor can be integrated seamlessly into any process.

Modbus Sensor Network with S331
The Modbus/RTU bus allows connecting several devices to a single bus line via Daisy-Chain. For example, up to 16 devices to a STUO Data Logger S331. The S331 is a powerful yet cost-efficient data logger and display solution.

MEASUREMENT
Dew Point
Accuracy
± 1 °C Td (0 ... 50 °C Td)
± 2 °C Td (-20 ... 0 °C Td)
Selectable units
°C, °F, bar(g), MPa(g), psi(g), % rH, g/m³,
mg/m³, g/m³ atm., mg/m³
Measuring range
-20 ... +50 °C Td
Repeatability
0.25 % from measured value
Sensor
Polymer
Response time (t90)
0 °C Td ➞ -20 °C Td ≤ 50 sec
-20 °C Td ➞ 0 °C Td ≤ 35 sec
@ 4 l/min
