VOC Volatile Organic Compound Meter Model UltraRAE 3000+ Number 1 best seller

Last updated: 22 ส.ค. 2568  |  1561 จำนวนผู้เข้าชม  |

VOC Volatile Organic Compound Meter Model  UltraRAE 3000+ Number 1 best seller

Organic compounds (VOC)
Model :  UltraRAE 3000+

The Honeywell UltraRAE 3000+ VOC meter is the most advanced compound-specific, photometric detector (PID) on the market, with an extended range of 0.05 to 10,000 ppm in VOC mode and 50 ppb to 200 ppm. Its gasoline-only mode makes it an ideal tool for applications ranging from refinery initial screening and plant maintenance to hazardous materials response, seawater spill response and refinery downstream inspection.

- Dual detection mode for total benzene exposure assessment: 60-second overview or 15-minute STEL measurement.
- High sensitivity to benzene (down to 50 ppb) provides a lower detection range for future benzene exposure limits.
- Reduce the risk of false alarms with advanced speciation methods.
- All VOC measurement modes with extended range of 0.05 to 10,000 ppm.

Prices start from 12,000 baht to 300,000 baht.

Main features
- Proven PID technology
- 3 seconds response in VOC mode or 60 seconds in mixed only mode.
- Extended range up to 10,000 ppm (in VOC mode) with improved linearity.
- Built-in humidity sensor
- Automatically check sampling time
- Highly specific readings, including a 9.8eV UV lamp and a RAE-Sep™ benzene lamp.
- New sampling probe design allows immediate visibility through the pipe.
- Multi-purpose VOC or gasoline-specific mode
- Real-time wireless with built-in Bluetooth and optional RAELink3 portable modem.
- RAE correction factors for more than 200 compounds

Easy to use
- Large graphics display
- Supports multiple languages
- Easy access to lights, sensors and batteries in seconds without tools.
Low cost of ownership

- Affordable analysis using low-cost RAE-Sep tubes
Applications
- Screening before entering the restricted area between the refinery and maintenance plant.
- Hazardous materials response
- Response to seawater leakage
- Downstream inspection of the refinery

Screen

- UltraRAE 3000 monitor model PGM-7360
- Built-in wireless communication module
- Data recording with ProRAE Studio II package for Windows® XP, Windows® Vista, or Windows® 7.
- Travel charger
- RAE UV lamps and RAE-Sep™ lamps
- Flex-I-Probe
- External filter
- Red rubber boots

- Alkaline battery adapter
- Light bulb cleaning kit
- Tool set
- Lithium-Ion (Li-Ion) battery with universal AC/DC charger and universal plug set.
- Operation CD-ROM
- Operation and maintenance manual

Sensor Specifications

Gas MonitorRangeResolutionResponse Time (T90)
VOCs0 to 99.99 ppm0.05 ppm< 3 sec
VOCs100 to 999.9 ppm0.1 ppm< 3 sec
VOCs1000 to 9999 ppm1 ppm< 3 sec
Benzene0 to 200 ppm0.05 ppm< 60 sec
Butadiene0 to 200 ppm0.05 ppm

< 60 sec


Benzene is an important industrial precursor, but it is also highly toxic to the body if consumed in quantities exceeding the standard. This is because benzene (C₆H₆) is a highly dangerous substance and is directly classified as a carcinogen by WHO and OSHA.


The health hazards of gasoline
Short-term exposure → causes dizziness, headache, drowsiness, eye and respiratory irritation.
Long-term exposure → affects the bone marrow, causing anemia, abnormal blood cells, and is a carcinogen (Leukemia).

Safety standards such as OSHA set a Permissible Exposure Limit (PEL) for benzene of only 1 ppm (8 hours).


Why do you need an UltraRAE 3000 Gasoline Meter?
1. Employee health protection
The meter helps detect gasoline leaks in real time, reducing the risk of workers being unknowingly exposed.

2. Compliance with laws and standards
Most factories are required to comply with safety standards such as OSHA, NIOSH, or Thai labor laws that specify chemical exposure limits.

3. Increase confidence in safety in the factory.
To make operators, administrators and auditing agencies confident in the safety control system.

4. Emergency alert
Newer models of gasoline meters (such as the UltraRAE 3000+ or ​​ppbRAE 3000+) have audible, visual, and vibrating alarms if the gasoline level exceeds the specified limits.

5. Prevent economic damage
Reduce the risk of sudden work stoppages, medical expenses, and damages from safety law violations.

Summarize
Having a benzene detector is not just a safety requirement, but a crucial tool for protecting life, health, and security of an organization, especially in chemical, oil, and petrochemical plants. Investing in a benzene detector is an investment in the long-term safety of both people and the business.
